Status:Active
Warranty:1 year limited warranty
SKU:SV9343.210
Expected delivery of quantity in 110 days
Quantity:
| Brand | Rittal |
| Cable outlet | : Top/bottom |
| Rated operating current max. | : 400 A |
| Note | : The technical data may vary for UR applications. Applications to UR only in conjunction with "Special Purpose Fuses". |
| Material | : Polyamide Fire protection corresponding to UL 94 Contact tracks: Electrolytic copper, silver-plated |
| For bar systems with centre-to-centre spacing | : 60 mm |
| For NH size | : 2 |
| Test specification | : IEC/DIN EN 60 947-3 |
| Article number: | : SV 9343.210 |
| Type of electrical connection | : Screw M10 |
| Clamping area for laminated copper bars | : Width: 50 mm Height: 10 mm |
| Colour | : Chassis: RAL 7035 Cover: RAL 7035/7001 |
